Holtek HT68F Series Manual page 126

• TM1DL Register – 10-bit STM
Bit 7
Name D7
R/W R
POR 0
Bit 7~0 TM1DL: TM1 Counter Low Byte Register bit 7~bit 0
TM1 10-bit Counter bit 7~bit 0
• TM1DH Register – 10-bit STM
Bit 7
Name —
R/W —
POR —
Bit 7~2 Unimplemented, read as "0"
Bit 1~0 TM1DH: TM1 Counter High Byte Register bit 1~bit 0
TM1 10-bit Counter bit 9~bit 8
• TM1AL Register – 10-bit STM
Bit 7
Name D7
R/W R/W
POR 0
Bit 7~0 TM1AL: TM1 CCRA Low Byte Register bit 7~bit 0
TM1 10-bit CCRA bit 7~bit 0
• TM1AH Register – 10-bit STM
Bit 7
Name —
R/W —
POR —
Bit 7~2 Unimplemented, read as "0"
Bit 1~0 TM1AH: TM1 CCRA High Byte Register bit 1~bit 0
TM1 10-bit CCRA bit 9~bit 8
Rev. 2.10
HT68F20/HT68F30/HT68F40/HT68F50/HT68F60
HT68FU30/HT68FU40/HT68FU50/HT68FU60
Enhanced I/O Flash Type 8-Bit MCU with EEPROM
6 5 4
D6 D5 D�
R R R
0 0 0
6 5 4
— — —
— — —
— — —
6 5 4
D6 D5 D�
R/W R/W R/W
0 0 0
6 5 4
— — —
— — —
— — —
126
3 2 1
D3 D2 D1
R R R
0 0 0
3 2 1
— — D9
— — R
— — 0
3 2 1
D3 D2 D1
R/W R/W R/W
0 0 0
3 2 1
— — D9
— — R/W
— — 0
���� 02� 201�
0
D0
R
0
0
D8
R
0
0
D0
R/W
0
0
D8
R/W
0
