Holtek HT68F Series Manual page 106

TMPC0 Register
• HT68F20
Bit 7
Name —
R/W —
POR —
Bit 7~6 Unimplemented, read as "0"
T1CP1: TP1_1 pin Control
Bit 5
0: Disable
1: Enable
Bit 4 T1CP0: TP1_0 pin Control
0: Disable
1: Enable
Bit 3~1 Unimplemented, read as "0"
Bit 0 T0CP0: TP0_0 pin Control
0: Disable
1: Enable
• HT68F30
Bit 7
Name T1ACP0
R/W R/W
POR 1
Bit 7 T1ACP0: TP1A pin Control
0: Disable
1: Enable
Bit 6 Unimplemented, read as "0"
Bit 5 T1BCP1: TP1B_1 pin Control
0: Disable
1: Enable
Bit 4 T1BCP0: TP1B_0 pin Control
0: Disable
1: Enable
Bit 3~2 Unimplemented, read as "0"
T0CP1: TP0_1 pin Control
Bit 1
0: Disable
1: Enable
Bit 0 T0CP0: TP0_0 pin Control
0: Disable
1: Enable
Rev. 2.10
HT68F20/HT68F30/HT68F40/HT68F50/HT68F60
HT68FU30/HT68FU40/HT68FU50/HT68FU60
Enhanced I/O Flash Type 8-Bit MCU with EEPROM
6 5 4
— T1CP1 T1CP0
— R/W R/W
— 0 1
6 5 4
— T1BCP1 T1BCP0
— R/W R/W
— 0 1
106
3 2 1
— — — T0CP0
— — —
— — —
3 2 1
— — T0CP1 T0CP0
— — R/W
— — 0
