PBC Register
• HT68F20/HT68F30
Bit 7
Name —
R/W —
POR —
Bit 7~6 Unimplemented, read as "0"
PBC: Port B bit 5~bit 0 Input/Output Control
Bit 5~0
0: Output
1: Input
PCC Register
• HT68F20
Bit 7
Name —
R/W —
POR —
Bit 7~4 Unimplemented, read as "0"
Bit 3~0 PCC: Port C bit 3~bit 0 Input/Output Control
0: Output
1: Input
PFC Register
• HT68F40/HT68F50
Bit 7
Name —
R/W —
POR —
Bit 7~2 Unimplemented, read as "0"
Bit 1~0 PFC: Port F bit 1~bit 0 Input/Output Control
0: Output
1: Input
PGC Register
• HT68F60
Bit 7
Name —
R/W —
POR —
Bit 7~2 Unimplemented, read as "0"
Bit 1~0 PGC: Port G bit 1~bit 0 Input/Output Control
0: Output
1: Input
