CDCLVP111-SP EVM Bill of Materials (BOM)
5 CDCLVP111-SP EVM Bill of Materials (BOM)
Table 3 displays the BOM.
Designator Qty Value
!PCB 1
C1, C2 2
C3, C4, C11 3 0.01uF
C5, C6 2 1000pF
C7, C8 2
C9, C10 2
H1, H2, H3, H4 4
H5, H6, H7, H8 4
J1 1
J2, J4 2
J3 1
J5, J6, J7, J8, J9, J10, J11, 24
J12, J13, J14, J15, J16, J17,
J18, J19, J20, J21, J22, J23,
J24, J25, J26, J27, J28
R1, R2, R4, R5 4
SH-J1 1
U1 1
R3 0
R6, R7, R8, R9, R10, R11, 0
R12, R13, R14, R15, R16,
R17, R18, R19, R20, R21,
R22, R23, R24, R25
8
CDCLVP111-SP Evaluation Module (CDCLVP111EVM-CVAL)
Table 3. Bill of Materials
Description
Printed Circuit Board
1uF CAP, CERM, 1 µF, 25 V, +/- 10%, X7R, 1206
CAP, CERM, 0.01 µF, 50 V, +/- 5%, X7R, 0603
CAP, CERM, 1000 pF, 50 V, +/- 10%, X7R, 0603
10uF CAP, TA, 10 µF, 25 V, +/- 20%, 1.5 ohm, SMD
68uF CAP, TA, 68 µF, 25 V, +/- 10%, 0.2 ohm, SMD
Machine Screw, Round, #4-40 x 1/4, Nylon, Philips panhead
Standoff, Hex, 0.5"L #4-40 Nylon
Header, 2.54 mm, 3x1, Tin, TH
BANANA JACK, SOLDER LUG, RED, TH
BANANA JACK, SOLDER LUG, BLACK, TH
JACK, SMA, 50 Ohm, Gold, SMT
49.9 RES, 49.9, 1%, 0.063 W, 0402
Shunt, 100mil, Gold plated, Black
CDCLVP111HFG, HFG0036A_Custom_A
0 RES, 0, 5%, 0.1 W, 0603
49.9 RES, 49.9, 1%, 0.063 W, 0402
Copyright © 2016, Texas Instruments Incorporated
Package Reference Part Number
MHR030
1206 C3216X7R1E105K085AA
0603 C0603C103J5RACTU
0603 C0603C102K5RACTU
6032-28 293D106X0025C2TE3
7343-43 T495X686K025ATE200
Screw NY PMS 440 0025 PH
Standoff 1902C
Header, 2.54 mm, 3x1, TH TSW-103-07-T-S
Red Insulated Banana Jack SPC15363
Black Insulated Banana Jack SPC15354
SMA JACK EDGE MNT, 73251-1150
SMT
0402 RC0402FR-0749R9L
Shunt 2 pos. 100 mil 881545-2
HFG0036A_Custom_A CDCLVP111HFG
0603 CRCW06030000Z0EA
0402 RC0402FR-0749R9L
www.ti.com
Manufacturer
Any
TDK
Kemet
Kemet
Vishay-Sprague
Kemet
B&F Fastener Supply
Keystone
Samtec
Tenma
Tenma
Molex
Yageo America
TE Connectivity
Texas Instruments
Vishay-Dale
Yageo America
SCAU055 – November 2016
