To set the respiration amplitude:
1. Push  or  to highlight the Amplitude value.
2. Push .
3. Push  or  to change the amplitude in 0.05 Ω steps between 0.00 Ω and
5.00 Ω.
4. Push  to set the amplitude and go back to the Respiration screen.
To set the baseline resistance:
1. Push  or  to highlight the Baseline value.
2. Push .
3. Push  or  to highlight 500, 1000, 1500, or 2000 Ω in the list.
4. Push  to set the baseline impedance and go back to the Respiration
screen. The baseline impedance is kept in memory and is non-volatile.
Baseline value is kept in memory and is non-volatile.
To set the respiration lead:
1. Push  or  to highlight the Respiration lead.
2. Push .
3. Push  or  to highlight LA or LL in the list.
4. Push  to set the respiration lead and go back to the Respiration screen.
The respiration lead is kept in memory and is non-volatile.
Respiration lead value is kept in memory and is non-volatile.
Set Apnea Simulation
You can simulate an apnea period manually or for a specified time period. To
control an apnea period manually, push the Continuous Apnea softkey from the
Respiration screen. The display shows a timer which shows the time since the
apnea period started. The respiration simulation is stopped when the Stop
softkey is pushed.
To do a timed apnea period:
1. Push the Timed Apnea softkey from the Respiration screen.
2. Push  or  to highlight 12, 22, or 32 seconds.
3. Push .
The display shows a timer that counts down the apnea period. When the timer
counts down to zero, the apnea period ends and the display shows the
Respiration screen. Push the Stop softkey to abort the apnea function.
