Fluke Biomedical ProSim 8 User Manual page 23

Simulation Name
Bradycardic
Ventricular Fibrillation
Asystole
After you set one of the pre-defined simulations, you can change the parameters
of one or all of the vital signs. Changes are not kept in the Product. The pre-
defined simulation parameters cannot be changed through the front panel.
There are seven custom pre-defined simulations in the Product. To set a custom
simulation:
1. From the Home screen, push the More softkey.
2. Push the Custom softkey.
Four custom simulation names show above the first four softkeys. The names
are Custom1, Custom2, Custom3, and Custom4. To show the next three
names, push the More softkey.
3. Push the softkey for a custom pre-defined simulation.
All the vital sign simulation parameters are set to the values contained in the pre-
defined simulation.
You can customize the seven factory simulations and seven custom simulations
through the Ansur functionality.
Table 7. Pre-Defined Patient Simulations (cont.)
Parameter
Wave Form
ECG Rate
Respiration Rate
Temperature
IBP Channel 1
IBP Channel 2
NIBP
SpO
2
Wave Form
ECG Rate
Respiration Rate
Temperature
IBP Channel 1
IBP Channel 2
NIBP
SpO
2
Wave Form
ECG Rate
Respiration Rate
Temperature
IBP Channel 1
IBP Channel 2
NIBP
SpO
2
Vital Signs Simulator
Pre-Defined Simulations
Pre-Set Value
NSR (Adult)
30 BPM
15 brpm
35.0 °C
100/65 mmHg (Art)
25/10 mmHg (PA)
100/65 (77) mmHg
85 %
Atrial Fibrillation (Coarse)
No BPM
70 brpm
34.0 °C
35/15 mmHg (Art)
35/0 mmHg (LV)
35/15 (22) mmHg
80 %
Asystole
0 BPM
0 brpm
33.0 °C
0 mmHg
0 mmHg
0/0 mmHg
50 %
11
