ProSim 8
Users Manual

Instrument Familiarization

Table 5 is a list of Product top-panel controls and connections.
18
17
16
15
14
Item
ECG Posts

ECG Function

NIBP Button

Special Functions

SETUP Button

IBP Button

Navigation Buttons

Enter Button

Backlight Button

Power Button

SpO

Function Softkeys

LCD Display

SpO

IBP Channel 2 Connector

Cardiac Output Connector

IBP Channel 1 Connector

Temperature Connector

6
Table 5. Top-Panel Controls and Connections
13
Name
Button
2
Connector
2
Top
1
F1 F2 F3 F4 F5
12
Connection posts for Device Under Test (DUT) ECG leads.
Accesses the ECG waveforms (adult, pediatric, and arrhythmias),
and ECG test functions (performance waves, QRS detection, Tall T
wave rejection, and R wave detection).
Accesses the Non-Invasive Blood Pressure (NIBP) functions.
Accesses the temperature, respiration, cardiac output, fetal
simulation, autosequences, and view memory functions.
Accesses the setup controls.
Accesses the Invasive Blood Pressure (IBP) functions.
Cursor control buttons for navigating menus and lists.
Sets the highlighted function.
Turns the display backlight on and off.
Turns the Product on and off.
Accesses the SpO functions.
2
Keys F1 through F5 are used to select from a number of selections
that appear in the LCD display above each function softkey.
Color display.
Connector to the SpO accessory.
2
Connector to an IBP input of the patient monitor.
Connector to the Cardiac input of the patient monitor.
Connector to the IBP input of the patient monitor.
Connector to the Temperature input of the patient monitor.
8
9
10
11
Description
2
3
4
5
6
7
glh034.eps
