Chapter 3

Pulse Output

Figure 29
counter/timer 0; in this example, an external gate is used. Refer to
more information about pulse output operations.
Heater
Controller
External
Gating
Switch
Figure 29: Connecting Counter/Timer Signals for a Pulse Output Operation Using an External Gate
58
shows how to connect counter/timer signals to perform a pulse output operation on
(Connected to the DT9857 or DT9857E)
Digital Ground
Counter 0 Out
Counter 0 Gate
Digital Ground
page 97 through page 98
STP25
16
15
12
10
for
