External Trigger Connector (DT9857E Only)
Figure 48
shows the layout of the external digital (TTL) connector on the DT9857E module.
Note that on the DT9857, the external digital (TTL) input is provided on pin 11 of the Digital
connector.
Figure 48: External Trigger Connector (DT9857E Module Only)
Connector Pin Assignments and LED Status Indicators
External Trigger In
External Trigger In Return
165
