Chapter 3

Edge-to-Edge Measurement

Figure 27
perform an edge-to-edge measurement operation using two signal sources. The counter
measures the number of counts between the start edge (in this case, a rising edge on the
Counter 0 Clock signal) and the stop edge (in this case, a falling edge on the Counter 0 Gate
signal).
You specify the start edge and the stop edge in software. Refer to
on edge-to-edge measurement mode.
Signal
Source 0
Signal
Source 1
Figure 27: Connecting Counter/Timer Signals for an Edge-to-Edge Measurement Operation
56
shows how to connect counter/timer signals to the STP25 screw terminal panel to
page 96
(Connected to the DT9857 or DT9857E)
Digital Ground
Counter 0 Clock
Counter 0 Gate
for more information
STP25
16
14
12
