A 25-pin Digital connector is provided for attaching digital I/O, external trigger, and
counter/timer signals.
DT9857 and DT9857E modules.
To make wiring easier, you can connect the STP25 screw terminal panel to the Digital
connector on the DT9857 or DT9857E module as shown in
The STP25 contains one 25-pin connector and a screw terminal block. The 25-pin connector
provides access to the signals from the Digital connector on the DT9857 and DT9857E
modules.
46
Figure 14
1
14
Figure 14: Layout of the Digital Connector
DT9857 or DT9857E
Module
Digital Connector
Figure 15: Connecting the STP25 to the DT9857 or DT9857E Module
Figure 16 shows the layout of the STP25 and lists the screw terminal assignments.
shows the layout of the 25-pin Digital connector on the
EP403
13
25
Figure 15.
STP25
