Chapter 2
5. For Windows Vista:
6. Repeat these steps until you have attached the number of expansion hubs and modules
Host Computer
Figure 10: Attaching Multiple DT9857 or DT9857E Modules Using Expansion Hubs
36
a. Click Locate and install driver software (recommended).
The popup message "Windows needs your permission to continue" appears.
b. Click Continue.
The Windows Security dialog box appears.
c. Click Install this driver software anyway.
Note: Windows 7, Windows 8, and Windows 10 find the device automatically.
that you require. Refer to
The operating system automatically detects the USB devices as they are installed.
USB Cable
Power Supply
for Hub
Figure 10.
Power Supply
DT9857 or
for Module
DT9857E
Module
USB Cables
DT9857 or
DT9857 or
DT9857E
Module
USB Cables
DT9857 or
DT9857E
Module
USB Cable
Expansion Hubs
Power Supply
for Hub
DT9857E
Module
