Appendix A

Power, Physical, and Environmental Specifications

Table 32
DT9857E modules.
Power
DT9857:
DT9857E:
Warm-up time
Physical Dimensions --DT9857 OEM (board only)
Length of Bottom Board:
Width of Bottom Board:
Thickness of Bottom Board:
Weight of DT9857-08-OEM:
Length of Top Board (used by DT9857-16-OEM only):
Width of Top Board (used by DT9857-16-OEM only):
Thickness of Top Board (used by DT9857-16-OEM only):
Weight of DT9857-16-OEM:
Physical Dimensions - DT9857E Enclosure
Length:
Width:
Height:
Weight of DT9857-08:
Weight of DT9857-16:
Physical Dimensions --DT9857E OEM (board only)
Length of Bottom Board:
Width of Bottom Board:
Thickness of Bottom Board:
Weight of DT9857-08-OEM:
Length of Top Board (used by DT9857E-16-OEM only):
Width of Top Board (used by DT9857E-16-OEM only):
Thickness of Top Board (used by DT9857E-16-OEM only):
Weight of DT9857E-16-OEM:
Environmental
Operating temperature range:
Storage temperature range:
Relative humidity:
Altitude:
156
lists the power, physical, and environmental specifications for the DT9857 and
Table 32: Power, Physical, and Environmental Specifications
Feature DT9857 and DT9857E Specifications
+5 VDC @ 10 W
+4.75 VDC to +28 VDC
1 hour
Card-cage mountable in 6 U cage;
8 channel = 4HP; 16 channel = 8HP;
0.8" (20.3 mm) spacing in center
8.661 in (220 mm)
9.187 in (233.3 mm)
0.063 in (1.6 mm)
487.2 g (17.2 oz)
5.473 in (139 mm)
9.187 in (233.3 mm)
0.063 in (1.6 mm)
800 g (28.2 oz)
Rack-mountable in 19" x 1U rack with EP402 kit
8.795 in (223.4 mm)
9.719 in (246.9 mm)
1.72 in (43.7 mm)
1155 g (40.8 oz)
1475.5 g (52.0 oz)
Card-cage mountable in 6 U cage;
8 channel = 8HP; 16 channel = 8HP;
0.8" (20.3 mm) spacing in center
8.661 in (220 mm)
9.187 in (233.3 mm)
0.063 in (1.6 mm)
516 g (18.2 oz)
5.473 in (139 mm)
9.187 in (233.3 mm)
0.063 in (1.6 mm)
833 g (29.4 oz)
0° C to 55° C
–
25° C to 85° C
To 95%, noncondensing
To 10,000 feet
