INTRODUCTION
1.4

System Components

The Liquidew I.S. Process Moisture Analyzer consists of:
• the sensor assembly
• the multi-channel control unit
Sensor Assembly
(Up to four channels can have any combination of Liquidew
I.S., Promet I.S. or Minox-i O
* Promet I.S. is a sister product of the Liquidew I.S. and is used for moisture in gas
measurement; Minox-i is an electrochemical oxygen sensor
4
c
b
a
sensors*)
2
a Temperature transmitter
b Sensor block
c Dew-point transmitter
d User interface
e Electrical connections - to hazardous area
f Electrical connections - non-hazardous
Figure 3 Major Components of the Liquidew I.S.
Liquidew I.S. User Manual
Control Unit
97092 Issue 6, July 2022
