Address Function Description
26 Liquid Selection
Liquid Mix Ratio
27
(% of Mixed Liquid 1)
28 User Cs Table 1, Cs Value at -20 °C
29 User Cs Table 1, Cs Value at -10 °C
30 User Cs Table 1, Cs Value at 0 °C
31 User Cs Table 1, Cs Value at 10 °C
32 User Cs Table 1, Cs Value at 20 °C
33 User Cs Table 1, Cs Value at 30 °C
34 User Cs Table 1, Cs Value at 40 °C
35 User Cs Table 1, Cs Value at 50 °C
36 User Cs Table 1, Cs Value at 60 °C
37 User Cs Table 1, Cs Value at 70 °C
38 User Cs Table 2, Cs Value at -20 °C
39 User Cs Table 2, Cs Value at -10 °C
40 User Cs Table 2, Cs Value at 0 °C
41 User Cs Table 2, Cs Value at 10 °C
42 User Cs Table 2, Cs Value at 20 °C
43 User Cs Table 2, Cs Value at 30 °C
44 User Cs Table 2, Cs Value at 40 °C
45 User Cs Table 2, Cs Value at 50 °C
46 User Cs Table 2, Cs Value at 60 °C
47 User Cs Table 2, Cs Value at 70 °C
Dew point (O
48
Dew point (O
49
Pressure (P) /Tempr (L)
50 Channel – ADC Val 4mA (n/a for O
Pressure (P) /Tempr (L)
51 Channel – ADC Val 20mA (n/a for
53 Analog Output 1 – DAC 4 mA Value
Michell Instruments
) Channel – ADC Val
2
4mA
) Channel – ADC Val
2
20mA
2
only)
O only)
2
Read/ Default
Write Value Configuration
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
