APPENDIX B
Register Configuration E – mA Output Config
15 14 13 12
Ouput1 Parameter (O1)
0000 = Dew point (O2)
0001 = Pressure/
Temperature
0010 = ppm
W
0011 = ppm (Ideal)
V
0100 = ppm (Nat Gas)
V
0101 = mgm
3
0110 = lbmmscf
Register Configuration F – Status Register
15 14 13 12
A4 A4 A3 A3
Relay Alarm Status flags (A1, A2, A3, A4)
Example:
A1 = 00=OK (relay de-energized)
A1 = 01=High (or Fault) (relay energized)
A1 = 10=Low (relay energized)
Pressure/Temperature Sensor Status (PS)
0=OK
1=Fault (or not available)
44
11 10 9 8
O3 O3 O3 O3
Output2 Parameter (O2)
0000 = Dew point (O2)
0001 = Pressure/
Temperature
0010 = ppm
W
0011 = ppm (Ideal)
V
0100 = ppm (Nat Gas)
V
0101 = mgm
3
0110 = lbmmscf
11 10 9 8
A2 A2 A1 A1
Liquidew I.S. User Manual
7 6 5 4
O2 O2 O2 O2
Output3 Parameter (O3)
0000 = Dew point (O2)
0001 = Pressure/
0010 = ppm
0011 = ppm
0100 = ppm
0101 = mgm
0110 = lbmmscf
7 6 5 4
Dew point Sensor Status (DS)
0=OK
1=Fault (or not available)
97092 Issue 6, July 2022
3 2 1 0
O1 O1 O1 O1
Temperature
W
(Ideal)
V
(Nat Gas)
V
3
3 2 1 0
PS DS
