Liquidew I.S. User Manual
C.4
Terminal Parameters
Ui
li
Pi
Ci
Li
C.5
Special Conditions
1.
The wiring connections to the free socket must be made via crimped
connectors in such a way that all the strands of the wire used are held
securely by the crimp.
2.
The plastic plug and socket create a potential for electrostatic discharge
so must not be rubbed with a dry cloth or cleaned with solvents.
3.
The Easidew PRO I.S Dew-Point Transmitter does not withstand the 500
V AC insulation test to frame. This must be taken into account when
installing the equipment.
C.6
Maintenance and Installation
The Easidew PRO I.S. must only be installed by suitably qualified personnel and in
accordance with the instructions provided and the terms of the applicable product
certificates.
Maintenance and servicing of the product must only be carried out by suitably trained
personnel or returned to an approved Michell Instruments Service Center.
Michell Instruments
= 28 V
= 93 mA
= 820 mW
= 37 nF
= 0
APPENDIX C
49
