3

Functional Description

This chapter provides a functional description of the major compo-
nents and devices on the AMC-7000.

3.1 Overview

The AMC-7000 contains three major functional blocks. These are:
1. The Serial Storage interface
2. The Power Regulator, and
3. The IPMI subsystem (Module Management Controller - MMC)
The following block diagram illustrates the major components and
switch locations on the AMC-7000.
Functional Description
AMC Fingers
Power Regulator
HDD Connector
SATA HDD

Figure 3-1: AMC-7000 Functional Blocks

Switch
MMC
AMC-7000
