To remove the AMC module, follow these steps:
1. Begin to remove your module by pulling the Module Handle
to the half way (HW) position. Do not remove the module
immediately.
2. Powering down or removing a board before the operating
system or other software running on the board has been
properly shut down may cause corruption of data or file sys-
tems.
3. If your module is hot swap compliant and you are running
fully functional hot swap-aware software, unlatching this
ejector lever will start the shutdown process on the board.
The software will slowly blink the blue hot swap LED indicat-
ing the module is in the process of being de-activated.
4. Once the module has been de-activated, the Blue LED will
solidly illuminate. Once this is done you can extract the
module by pulling on the module handle.
5. WARNING: Some AMC-7000 models may display this
symbol to indicate the possible presence of a hot
surface or component reaching up to 85ºC. To reduce
the risk of injury from a hot component when servicing,
allow the surface to cool before touching.
6. If your board or system is not running hot swap-aware soft-
ware, the blue LED may illuminate without regard to soft-
ware processes still running on the board. Be sure to
manually shut down applications or operating systems run-
ning on the board prior to board removal.
7. Carefully pull the module from the chassis. If the card slot is
to remain empty, install a filler panel in the slot.
