2.4 Installing the AMC-7000 Module

This section describes a recommended procedure for installing a
board module in a chassis.
Before you install your module, please read all cautions, warnings,
and instructions presented in this section.
Handling modules and peripherals can result in static damage.
Use a grounded wrist strap, static-dissipating work surface, and
antistatic containers when handling and storing components.
CAUTION:
Insert the board by holding the Module Handle—do not exert
unnecessary pressure on the faceplate.
Hot swap compliant modules may be installed while the system
is powered on. If a module is not hot swap compliant (or the
system does not support hot swap), you should remove power
CAUTION:
to the slot or system before installing the module.
6

Figure 2-1: AMC Module Handle

Installation
