Orthman 1TRIPR II ROW UNITS Operator's Manual page 69

This table has been created to help understand the
effects that the set bolt and spring tension setting have
on the AR trip linkage's ability to trip. The numbers
shown in the chart represent the estimated amount of
force (lb/kg) that is required to trip the tail when the shank
is at the deepest setting.
As the spring tension is increased (tightened up) and the
set bolt setting is decreased (unscrewed), the force
required to trip is increased.
4-1/2 full turns in
3-1/4 full turns in
Set Bolt Setting
2-1/4 full turns in
1 full turn in
13
14
15
16
Figure 5-18: Set Bolt Setting
13) Stop block
14) Rear trip link
15) Jam nut
1TRIPR II Row Units OM-EN
Distance
1/4 in
(0.64 cm)
3/16 in
(0.48 cm)
1/8 in
(0.32 cm)
1/16 in
(0.16 cm)
0 in
0 turns
(0 cm)
17
ORM000300
16) Set bolt
17) Set bolt setting
OPERATION AND FIELD SETTINGS
Spring Tension Setting
1-3/16
(3.02 cm)
3352 lb
(1520 kg)
4096 lb
(1858 kg)
4841 lb
(2196 kg)
5958 lb
(2703 kg)
*8565 lb
(3885 kg)
Orthman Manufacturing encourages the operator to start out
at the factory setting, where the row unit tail will trip very
easily. From that point adjust the set bolt and spring tension
to attain the desired AR trip linkage setting.
The standard version of the 1tRIPr® II without the AR trip
linkage is equipped with a shear bolt. See "Shear Bolt
Protected Tail" on page 5-20. The amount of force it takes to
shear this bolt is slightly over 8000 lb (3629 kg).
*Notice that the chart has values that exceeds 8000 lb
(3629 kg). Orthman Manufacturing recommends using
extreme caution when adjusting the AR trip linkage to a
setting above 8000 lb (3629 kg). Using a setting that exceeds
the 8000 lb (3629 kg) mark is likely to increase the chances
of damaging the shank in the event an obstacle is
encountered.
5-23
1 in 7/8 in
(2.54 cm) (2.22 cm)
6331 lb 6703 lb
(2872 kg) (3040 kg)
6889 lb 7076 lb
(3125 kg) (3210 kg)
7262 lb 7262 lb
(3294 kg) (3294 kg)
7448 lb *8193 lb
(3378 kg) (3716 kg)
*8938 lb *9682 lb
(4054 kg) (4392 kg)
