MAJOR COMPONENTS

Rolling Basket Assembly

NOTE: The 14 inch berm-promoting rolling basket is
shown. The 14 inch standard, 8 inch narrow
standard, and 10 inch vertical tillage rolling
baskets are similar.
1) Spring
1
Figure 3-3
2) Basket frame
3-4
2
3
3) Basket
1TRIPR II Row Units OM-EN
ORM000058
