OPERATION AND FIELD SETTINGS

Row Cleaner Assembly Width

The row cleaner assembly reduces field residue directly
behind the depth band coulter assembly prior to the
arrival of rearward tooling. The row cleaner assembly can
be adjusted fore and aft.
The row cleaner discs can be adjusted fore and aft by
removing them and changing their position to one of
three holes on the row cleaner mount. Each rearward
hole moves the disc assembly nearly 1 in (2.54 cm)
further away from the depth band coulter. As the discs
are moved rearward, the distance between the discs will
increase.
There are two spacers along with a washer that set the
width between the discs. A combination of these spacers
may be used to attain different widths between discs at
different fore and aft positions. As discs are moved
rearward, it is adviseable to remove spacers to decrease
the width between the discs.

Fore and Aft Adjustment

NOTE: Adjustment for left row cleaner disc is shown.
Adjustment for right row cleaner disc is similar.
Tools
• Snap ring pliers
• 1-1/8 in Wrench
DANGER
!
Avoid crushing. Failure to follow this information will
result in death or serious injury. Make sure all personnel
are clear of the implement before lowering.
DANGER
!
Avoid crushing. An uneven surface could cause the
implement to shift or fall, resulting in injury or death as
well as implement damage. Park the implement on a
clean, dry, level surface.
DANGER
!
Avoid crushing. Failure to follow this information will
result in death or serious injury. Use bar stands and
cylinder stops to support the implement.
1. Lower the implement to the ground, place the tractor
in park, turn off the engine, and remove the key.
2. Remove buildup of grease, oil, and debris prior to
adjusting row cleaner assembly width. See
"Implement Inspection" on page 7-4.
CAUTION
!
Be extremely careful working around unshielded sharp
edges. Injury may result from contact with sharp edges.
3. Remove snap ring (1) and cap (2).
4. Remove nut (9), washer (8), bushings (6 and 7), and
bolt (4).
5. Adjust the left row cleaner disc (5) to desired
position.
6. Install bolt, bushings, washer, and nut.
7. Tighten nut and bolt to specification. See "Torque
Specifications" on page 7-2.
8. Inspect O-ring (3) and replace if necessary.
9. Install cap and snap ring.
