SAFETY INFORMATION

Warning and Safety Lights

Oversized implements and slow moving vehicles create a
hazard when transported on public roads. Use safety
lighting when traveling on public roads day and night.
Make sure all warning lights, safety lights, and turning
signals are working and clean. Replace missing or
damaged lights immediately. Comply with state and local
laws governing implement safety lighting.
3
1
2
1) Orange fluorescent non-reflective decal (6 used)
2) Red retroreflective decal (6 used)
3
1
1
2
2
Figure 2-1

Rear View of Toolbar

See Figure 2-1.
NOTES:
• Two-sided amber lights (3) must be visible from the
front and rear of the implement.
• Orthman double bar toolbar is shown. Orthman rigid
toolbar is similar.
4
3
1
1
2
3) Two-sided amber light (4 used)
4) Yellow reflective decal (4 used)
2-6
3
4
A
3
A
2
