Installation
A
1
320 (12.6)
14
5
Installation
5.1
Dimensions of LT5
Dimensions of common components are used for the installation conditions. Contact your
Endress+Hauser Sales Center if you are using different components.
5.1.1
Dimensions of LT5-1 (threaded, low-pressure type)
153
(6.02)
4-M10
3
LT5-1 / float dimensions. Unit of measurement mm (in)
A
Gauge head (ADC12)
B
Float φ140 (SUS316)
C
Float φ400 (SUS316)
D
Float φ140 (PVC)
E
Float φ400 (PVC)
1
Union nut (select from JIS Rc 1-1/2 /ANSI NPT 1-1/2; if there is no union nut, select Rp 1-1/2)
B
C
Ø140
(5.51)
D
E
Ø140
(5.51)
Float level gauge LT5
Ø400 (15.74)
Ø410 (16.14)
440 (17.32)
Ø400 (15.74)
Endress+Hauser
A0041186
