Accessories
90
265 (10.43)
90
(3.54)
175 (6.89)
 71 Gauge supporter (high pressure). Unit of measurement mm (in)
1 Pipe supporter (not supplied)
2 Center line of the mounting position
3 Gauge supporter (based on the selected option SS400: t = 4.0 / SUS304: t = 4.0), mounting bolt
4 Center line of the gauge supporter
1
2
R9 (0.35)
3
Float level gauge LT5
25 (0.98)
4
50 (1.97)
20 (0.79) 30 (1.18)
Endress+Hauser
A0041180
