Installation
30
27
Measuring tape and wire (example: option 1 for specification 070 and option 5 for specification 060)
1
Perforated tape
2
Non-perforated tape / wire
In the above diagram, the maximum measurable distance is 22 mm, and there is up to
23 m of clearance. For this reason, the total length of the measuring tape is 45 m.
1
2
Float level gauge LT5
A0041195
Endress+Hauser
