Product description
Items
Low-pressure
type
Low-pressure
type
High-pressure
type
Float φ140 Low-pressure
type
Low-pressure
type
Display coupling
(coupling between the internal parts of
the gauge head and the display)
Total weight LT5-1
LT5-4
LT5-6
Painting color
10
Description
Weight: 5.0 kg
Weight: 8.0 kg
Weight: 8.3 kg
Weight: 2.1 kg
Weight: 2.4 kg
LT5-1
(threaded, low-pressure type)
LT5-4
(flange, medium-pressure
type)
LT5-6
(flange, high-pressure type)
Threaded/flange,
low-pressure type
Flange, medium-pressure type Approx. 22 kg
Flange, high-pressure type
Gauge head
Other parts
For the low-pressure type, select SUS316 or PVC as the material.
3.3

List of material standards

Aluminum
Code Description
ADC12 Aluminum alloy die casting (SI-Si-Cu)
AC4CT6 Aluminum alloy casting (Si7Mg)
AC4A Aluminum alloy casting (Si10Mg)
Stainless steel
Code Description
SUS304 Stainless steel (18Cr-8Ni)
SUS316 Stainless steel (18Cr-12Ni-2.5Mo)
SCS13 Stainless cast steel equivalent to SUS304
SCS14 Stainless cast steel equivalent to SUS316
Other
Code
SGP (white pipe)
PVC
ρ: Liquid density (g/cm 3 ): 0.65 ≤ ρ < 1.05
3
ρ: Liquid density (g/cm ): 1.05 ≤ ρ < 2.0
ρ: Liquid density (g/cm 3 ): 0.5 ≤ ρ < 0.7
3
ρ: Liquid density (g/cm ): 0.5 ≤ ρ < 0.94
ρ: Liquid density (g/cm 3 ): 0.94 ≤ ρ < 2.0
Coupling: Penetration shaft
Coupling: Pressure bulkhead magnet coupling
Coupling: Pressure bulkhead magnet coupling
Approx. 8 kg
Approx. 100 kg
E+H Blue
Silver
Description
Carbon steel pipe
Polyvinyl chloride
Float level gauge LT5
