Float level gauge LT5
Endress+Hauser
5.10.6
Mounting on a tank top (guide pipe method)
33
Tank top mounting, unit. Unit of measurement mm (in)
1
Gauge head
2
Gauge supporter
3
Ventilation hole
4
Triangle bracket for measuring wire
5
Guide pipe (Stillwell)
6
Float
1
2
3
4
5
6
Ø140 (5.51)
Installation
A0041201
43
