Endress+Hauser Float level gauge LT5 Operating Instructions Manual page 15

Float level gauge LT5
A
11
(0.43)
90 (3.54)
A
280 (11.02)
80
(3.15)
1
Endress+Hauser
B
32 (1.26)
Ø52 (2.05)
 4 Accessory 1. Unit of measurement mm (in)
A Gauge supporter (select from iron / SUS304)
B Top anchor (ADC6)
C Top anchor (SUS316 / socket welding type)
D Top anchor (PVC) (only flange type is available for PVC.)
1 Select from JIS R1 / ANSI NPT1
B
330 (12.99)
80
(3.15)
120 (4.72)
1
2
 5 Accessory 2. Unit of measurement mm (in)
A Seal pot (select from aluminum / SUS316)
B Seal pot (PVC) (only flange type is available for PVC)
C Anchor hook (select from iron / SUS316)
D Anchor hook (PVC bolt)
E 90 ° sheave elbow (select from ADC6 / SCS14)
1 Threaded (select from Rp1-1/2 / NPT1-1/2 as an option)
2 Flange (select from JIS 10K 40A FF / ASME NPS1-1/2" Cl.150 FF / JPI 40A 150 lbs FF)
The 75 mm in seal pot 98/75 indicates the dimension for SUS316.
C
1
Ø42.7 (1.68)
C
2
Ø13
(0.51)
32 (1.26)
D
Ø20
(0.79)
32 (1.26)
Installation
D
4.5/4
(0.18/0.16)
40 (1.57)
E
(4.72)
4.5/4
(0.18/0.16)
40 (1.57)
1
A0041188
120
A0041189
15
