Installation
A
1
320 (12.6)
A
11
(0.43)
90 (3.54)
16
5.1.2
Dimensions of LT5-1 (flange, low-pressure type)
153
(6.02)
4-M10
6
Dimensions of LT5-1. Unit of measurement mm (in)
A
Gauge head (ADC12)
B
Float φ140 (SUS316)
C
Float φ400 (SUS316)
D
Float φ140 (PVC)
E
Float φ400 (PVC)
1
Flange (select from JIS 10K 40A RF / ASME NPS1-1/2" Cl.150 RF / JPI 40A 150 lbs RF)
B
32 (1.26)
7
Accessory 1 . Unit of measurement mm (in)
A
Gauge supporter (select from iron / SUS304)
B
Top anchor (ADC6+AC4A)
C
Top anchor (SUS316)
D
Top anchor (PVC)
1
Flange (select from JIS 10K 40A RF / ASME NPS 1-1/2" Cl.150 RF / JPI 40A 150 lbs RF)
2
Flange (select from JIS 10K 40A FF / ASME NPS 1-1/2" Cl.150 FF / JPI 40A 150 lbs FF)
B
C
Ø140
(5.51)
D
E
Ø140
(5.51)
C
49 (1.93)
1
Float level gauge LT5
Ø400 (15.74)
Ø410 (16.14)
440 (17.32)
Ø400 (15.74)
D
1
2
Endress+Hauser
A0041187
A0041191
