Installation
36
Order code examples (LT5-111C022B11A100000000)
Items Target
020 Gauge head
030 Gauge head process connection
040 Display; cover
050 Crank unit
060 Measuring range
070 Measuring tape
080 Float
090 Top anchor
100 Guide wire
110 Anchor hook; mounting bolt
120 90 ° sheave elbow
130 135 ° sheave elbow
140 Seal pot
150 Gate valve
Code Specifications
1 0.01961 MPa/2.84 psi,
aluminum (ADC12)
11 Rc 1-1/2, union nut, SUS316,
thread JISB0203
C Reverse mounting, dial display, acrylic
0 None
2 5 m
2 Measuring tape, tank top mounting
B D 400 mm SUS316 tape connection 5.0 kg,
0.65 ≤ density 1.05, with ring
11 2x R1, aluminum (ADC6),
thread JIS B0203
A Single wire with 3 mm diameter x 2 wires
1 Iron; SUS316
000 None
000 None
0 None
0 None
Float level gauge LT5
Qua
ntity
1
2
-
