Chapter 2: Jumpers and Switches

DIP Switch Settings

MCU Input Voltage

Connector location: SW3
1 2
POWERSW (Pin1)
OFF
OFF
ON
Copyright © 2022 NEXCOM International Co., Ltd. All Rights Reserved.
12V24V (Pin2)
Result
OFF
12V
ON
24V
ON
9~36V
12
VTC 210 Series User Manual
