Chapter 2: Jumpers and Switches

Power Button Connector

Connector location: SW2
1
2
1
2
4
3
4
3
A1
C1
A1
C1
MH2
MH1
MH1
MH2
Pin
Definition
1
GND
3
PWRBT_IN#
A1
LEDPWR_A1
Copyright © 2022 NEXCOM International Co., Ltd. All Rights Reserved.
Pin
Definition
2
PWRBT_IN#
4
GND
C1
LEDPWR_C1

Channel Switch

Connector location: SW4
1
4
1
4
3
2
2
3
MH2
MH1
MH1
MH2
Pin
Definition
1
UP_SW
3
GND
MH1
GND
17
Pin
Definition
2
DOWN_SW
4
GND
MH2
GND
