M.2 3042 Key B Socket; Connector Location: Cn2 - Nexcom VTC 210 Series User Manual

Chapter 2: Jumpers and Switches

M.2 3042 Key B Socket

Connector location: CN2

75 74
1 2
Pin Definition
1 CONFIG_3
3 GND
5 GND
7 USB_0P
9 USB_0N
11 GND
21 CONFIG_0
23 LTE_WAKE#
25 NC
27 GND
29 USB3_RX1N
31 USB3_RX1P
33 GND
35 USB3_TX1N
37 USB3_TX1P
39 GND
41 NC
Copyright © 2022 NEXCOM International Co., Ltd. All Rights Reserved.
Pin Definition
2 VCC3
4 VCC3
6 POWER_OFF#
8 W_DISABLE1#
10 LTE_LED#_A
20 PCIE_DIS
22 VBUS_SENSE
24 NC
26 W_DISABLE2#
28 NC
30 UIM_RST_A
32 UIM_CLK_A
34 UIM_DAT_A
36 UIM_PWR_A
38 NC
40 NC
42 NC
Pin Definition
43 NC
45 GND
47 NC
49 NC
51 GND
53 NC
55 NC
57 GND
59 NC
61 NC
63 NC
65 NC
67 M2_RSET#_R_A
69 CONFIG_1
71 GND
73 GND
75 CONFIG_2
27
Pin Definition
44 NC
46 NC
48 NC
50 NC
52 NC
54 NC
56 NC
58 NC
60 NC
62 NC
64 NC
66 SIM-DET
68 NC
70 VCC3
72 VCC3
74 VCC3
