Provisioning

The Logon Screen

The maintenance terminal screens allow you to monitor, provision, and troubleshoot an HDSL2 system.
To select a menu from the HiGain HDSL2 logon screen
•
Type the first letter of the menu.
← →
•
Use the arrow keys to select a menu, then press
Table 3 summarizes the navigational keys. They are also listed in the onscreen Help menu.
describes the Logon in screen menus.
Table 3. Navigational Keys for the Maintenance Terminal Screens
(a)
Key
SPACEBAR
ENTER
ESC or F11 (VT-100 only)
or CTRL + E
↑
↓ or CTRL + X
→
CTRL D
or +
←
or CTRL + S
CTRL + R
(a) Older management units require use of control keys instead of arrow keys.
8
Function
Cycle through selections.
Activate the current setting or choice, or display a menu.
Return to the parent menu.
Select the submenu or item above the current one, or return to the previous menu.
Select the submenu or item below the current one.
Select the menu or item to the right of the current one.
Select the menu or item to the left of the current one, or return to the previous menu.
Refresh the screen.
March 14, 2000
(Figure 3 on page 9), do one of the following:
ENTER .
152-202-116-02, Issue 2
Table 4 on page 9
