Performance History At The Ds1 Interface - ADC HiGain H2TU-C-202 User Manual

Monitoring System Activity and Performance

Performance History at the DS1 Interface

Figure 13 is an example of an H2TU-R 31-day DS1 performance screen as viewed from the line unit. In addition,
there are 48-hour, 25-hour, and current statistic screens for the DS1 interface for the H2TU-R as well as the
H2TU-C. Table 12 describes the acronyms used in the performance history screens.
Monitor Performance
------------------------------------------------------------------------------
Date ES-L
02/01 -
02/02 -
02/03 -
02/04 -
02/05 -
02/06 -
02/07 -
02/08 -
02/09 -
02/10 -
02/11 -
02/12 14
02/13 0
------------------------------------------------------------------------------
Press <Space> to cycle through
choices and <Enter> to view
ID: xxxx--xxxx--xxxx--xxxx
Table 12. Error Acronyms Used on the DS1 Performance History Screens
Acronym Description
ES-L Errored Seconds - Line
Seconds with BPV ≥1.
CV-P Code Violation - Path
Total count of FE errors for SF, or CRC-6
errors for ESF.
SES-L Severely errored seconds - Line
Seconds with BPV plus EXZ ≥1544 or
LOS ≥1.
CV-L Code Violation - Line
Total BPV count.
UAS-L Unavailable seconds - Line
Seconds with LOS ≥1.
ES-P Errored Seconds - Path
Seconds with SEF
(SF) ≥1.
(e)
FE
(a) FE is a frame bit error.
(b) Only appears on H2TU-R Performance History screens.
(c) Only appears on the H2TU-R Blockage Indicator (BI) History screen.
(d) Severely Errored Frame—Two or more frame bit errors occurring in a 0.75 ms interval for SF or a 3 ms interval for ESF.
(e) FE is a frame bit error.
28
Event Log Config
H2TU-R DS-1 31 Day History (Page 1 of 3)
SES-L UAS-L CV-L
- - -
- - -
- - -
- - -
- - -
- - -
- - -
- - -
- - -
- - -
- - -
10 10 10
0 0 0
Press: (N)ext Page, (P)revious Page, C(l)ear History
Interface
Statistics : 31 Day History
02/15/00 12:30:01
Figure 13. H2TU-R DS1 31-day Performance History
(d)
, CRC (ESF) or
March 14, 2000
Inventory Rlogon
CV-P ES-P SES-P
- - -
- - -
- - -
- - -
- - -
- - -
- - -
- - -
- - -
- - -
- - -
12 10 0
2 0 0
: H2TU-R DS-1
H2TU-C
Acronym Description
SES-P Severely errored seconds - Path
Seconds with SES or CRC(ESF) ≥320 or
(SF) ≥8 (F
(a)
FE
UAS-P Unavailable seconds - Path
A second of unavailability based on SES-P or AIS ≥1.
(b)
PRM-NE Performance Report Monitoring - Near End
The PRM from CPE indicates errors, and the signal
received from the network at the remote is error-free.
(b)
PRM-FE Performance Report Monitoring - Far End
The PRM from the network indicates errors, and the
signal received from the CPE is error-free.
(c)
B8ZSS B8ZS Monitored Seconds
Seconds with B8ZS detection when AMI option is active.
(c)
MSEC Monitored Seconds of the current (15 minute/1 hour/1
day) screen.
(c)
BI BI = [0.2 x ES + 0.4 x SES + UAS)/ MSEC] x 100%
(MSEC is the same as the DS1 MSEC)
