ADC HiGain H2TU-C-202 User Manual page 23

152-202-116-02, Issue 2
Table 5. H2TU-C-202 List 1F Standard Config Screen Options (Cont.)
System Settings Screen
Screen Options Display Code
H2TU-R TLOS TLOS
Loopback
Network NLBP
Loopback Pattern
Table 6. H2TU-C-202 List 1F PairGain Config Screen Options
System Settings Screen Screen
Options Display Code
Line Power Feed PWRF
Remote Provisioning RTPV
Bipolar Violation BPVT
Transparency
(See "Bipolar Violation
Transparency (BPTV)
Option" on page 18.)
DS1 BER Threshold DBER
(See "DS1 BER (DBER)
Option" on page 19.)
HDSL2 BER Threshold HBER
(See "HDSL2 BER (HBER)
Option" on page 18.)
Special Loopback Mode SPLB
SmartJack Loopback LPBK
H2TU-C-202 List 1F
Selection Description
ENA Enables a logic loopback at the H2TU-R when an LOS occurs at its DS1 input,
if enabled at the H2TU-R. For priority resolution, see
DIS Disables Transmit Loss of Signal (TLOS) logic loopback.
AIS Enables the H2TU-R to transmit an AIS towards CI for any network loopback.
For priority resolution, see
LOS Enables the H2TU-R to transmit an LOS towards CI for any network
loopback.
Selection Description
OFF Disables powering to the HDSL2 pair.
ON Keeps the HDSL2 line voltage at nominal -185 Vdc.
ENA Enables remote provisioning.
DIS Disables remote provisioning.
ENA Enables HDSL2 CRC and BPV errors at the DS1 input to be converted into
DS1 BPVs at the DS1 output at the distant end. This makes HiGain HDSL2
transparent to BPVs.
DIS Disables BPV Transparency.
ENA Enables the fixed 24-hour DS1 BER threshold (10
DIS Prevents the generation of a system alarm due to DS1 BER.
NONE Prevents generation of a system alarm due to BER.
1E-7 System alarm is initiated and the HCRC LED turns red when BER exceeds
-7
10 .
1E-9 System alarm is initiated and the HCRC LED turns red when the Block
Error Rate exceeds 10
Error Rate.)
NONE Prevents generation of a system alarm due to BER.
GNLB Configures the HiGain HDSL2 system to respond to the generic inband
loopback codes.
A1LB and Configures the HiGain HDSL2 system to respond to the inband loopback
A2LB codes of the Teltrend addressable repeater.
A3LB Configures the HiGain HDSL2 system to respond to the inband loopback
codes of the Wescom addressable repeater.
A4LB Configures the HiGain HDSL2 system to respond to the inband loopback
codes of the Wescom Mod 1 addressable repeater.
A5LB Configures the HiGain system to respond to the inband loopback codes
of the Teltrend Mod 1 addressable repeater.
ENA Enables the HiGain HDSL2 system to recognize all inband SmartJack
(SMJK) loopback commands.
DIS Configures the HiGain HDSL2 system to ignore all inband SmartJack
loopback commands.
March 14, 2000
Figure 22 on page
Figure 22 on page 37.
-6
).
-9
. (Block Error Rate is based on the definition of Bit
Provisioning
37.
15
