Monitoring System Activity and Performance

Current Statistics Screens for the DS1 Interface

Examples of current statistics screens are shown below.
interface at the remote unit and line unit, respectively. These screens report 15 minute, 1 hour, and 1 day statistics.
Refer to Table 12 on page 29
Monitor Performance
------------------------------------------------------------------------------
1 Day
Start 00:00
ES-L 0
SES-L 0
UAS-L 0
CV-L 0
CV-P 0
ES-P 0
SES-P 0
UAS-P 0
PRM-NE 0
PRM-FE 0
B8ZSS 0
MSEC 3482
------------------------------------------------------------------------------
Press <Space> to cycle through
choices and <Enter> to view
ID: xxxx--xxxx--xxxx--xxxx
Monitor Performance
------------------------------------------------------------------------------
1 Day
Start 00:00
ES-L
SES-L
UAS-L
CV-L
CV-P
ES-P
SES-P
UAS-P
B8ZSS
MSEC 3482
------------------------------------------------------------------------------
Press <Space> to cycle through
choices and <Enter> to view
ID: xxxx--xxxx--xxxx--xxxx
30
for descriptions of the kinds of errors reported on these screens.
Event Log Config
H2TU-R DS-1
1 Hour 15 Min
12:00 12:30
0 0
0 0
0 0
0 0
0 0
0 0
0 0
0 0
0 0
0 0
0 0
1801 1
Press: C(l)ear Current Statistics
Interface
Statistics :
02/15/00 12:30:01
Figure 15. H2TU-R DS1 Current Statistics
Event Log Config
H2TU-C DS-1 Current Statistics
1 Hour 15 Min
12:00 12:30
0 0 0
0 0 0
0 0 0
0 0 0
0 0 0
0 0 0
0 0 0
0 0 0
0 0 0
1801 1
Press: C(l)ear Current Statistics
Interface
Statistics :
02/15/00 12:30:01
Figure 16. H2TU-C DS1 Current Statistics
