Using The Performance Screens To View Performance Data - ADC HiGain H2TU-C-202 User Manual

152-202-116-02, Issue 2
U P
SING THE ERFORMANCE
The Performance screens display:
• CRC statistics for the HDSL2 or DS1 interface in 31-day, 48-hour, 25-hour, and current history reports.
• Alarm statistics for the HDSL2
on page 35) on a continuous basis.
•
Following a remote logon, Blockage Indicator statistics for the current hour and the last 8 hours at the
H2TU-R DS1 interface
To view the Blockage Indicator (BI) History screen,
remote unit before proceeding with steps 1 through 3 that follow.
To access the Performance history screens:
1 Type P to select the Performance screen.
2 Press the SPACEBAR
HDSL2), then press
3 Press the SPACEBAR
History, 31 Day History, or BI History) then press
When logged on to the H2TU-R remote unit, type
H2TU-C-202 List 1F
S
CREENS TO
(Figure 21 on page
(Figure 18 on page 33).
to select either interface (H2TU-C DS1, H2TU-R DS1, H2TU-C HDSL2, or H2TU-R
ENTER . Select H2TU-R DS1 if you wish to view the BI History screen.
to select the type of statistics (Current, Alarm History, 25 Hour History, 48 Hour
March 14, 2000
Monitoring System Activity and Performance
V P
IEW ERFORMANCE
36) or DS1 interfaces (Figure 19 on page 34
R to log on to the H2TU-R
type
ENTER
.
R to return to the H2TU-C logon screen.
D
ATA
and Figure 20
27
