152-202-116-02, Issue 2
U E
SING THE VENT
To view a running log of system events, press
time of the 100 most recent events (most recent displayed first) and provides a description of each event.
•
Press N or P to page through the event log.
•
Press T to return to the top of the log.
•
Press L to clear the event log.
Monitor Performance
------------------------------------------------------------------------------
# Location
1 System
2 System
3 System
4 System
5 System
6 System
7 H2TU-C
8 H2TU-C
9 H2TU-R
10 H2TU-R
11 System
12 H2TU-C
13 H2TU-C
14 - Empty -
15 - Empty -
Press: (N)ext Page, (P)revious Page, (T)op of Log, C(l)ear Log
ID: xxxx--xxxx--xxxx--xxxx
U S
SING THE ECTIONALIZED
The Sectionalized Event Log screen
sectionalized events for all four legs of the H2TU-R DS1 interface (see
provides a description of each event with the most recent event displayed first.
Sectionalized events isolate trouble to a particular circuit leg. For example, an ES listed under the NET-TX
column indicates an errored second condition exists on the NET-TX circuit leg beginning with the time stamp and
continuing until an OK or other new event is recorded.
On signals without FAR END or NEAR END PRM present, event data in the CPE-RX and NET-RX
circuit legs will be limited to trouble alarms.
To view the H2TU-R Sectionalized Event Log, type
• N P
Press or to page through the event log.
•
Press T to return to the top of the log.
•
Press L to clear the event log.
H2TU-C-202 List 1F
L T
OG TO RACK
E to select the Event Log. The Event Log displays the date and
Event Log Config
System Event Log (Page 1 of 7)
Date and Time
02/15/00 12:25:00
02/15/00 12:25:00
02/15/00 12:25:00
02/15/00 12:25:00
02/15/00 00:13:32
02/15/00 00:13:27
01/31/00 00:13:27
01/31/00 00:11:16
01/31/00 00:10:43
01/31/00 00:10:30
01/31/00 00:04:11
01/31/00 00:00:40
01/31/00 00:00:02
02/15/00 12:30:01
Figure 23. System Event Log
E
VENT
(Figure 24 on page
March 14, 2000
Monitoring System Activity and Performance
S E
YSTEM VENTS
Inventory Rlogon Help
Entry
DS1 Alarm Register reset
HDSL2 Alarm Register Reset
DS1 Performance Register Reset
HDSL2 Performance Register Reset
Time set 12:25:00
Date set 02/15/00
NLOC: Loop-down
NLOC: Loop-up
DS1 LOS Alarm: End
DS1 LOS Alarm: Begin
DS1C: AUTO to AMI
HDSL2 LOSW Alarm: End
HDSL2 LOSW Alarm: Begin
H2TU-C
L I
OG TO SOLATE
39) displays the date and time of the 100 most recent
Figure 11 on page
R
to logon remotely, then type
System: OK
T
ROUBLE
25). The screen
E
.
37
