Casio QT-8000 Service Manual page 46

CPU/SYS FAN SPEED:
Show you the current CPU/System FAN speed.
VCORE:
This item shows you the current system voltage.
+3.3V/+5V/+12V:
This item shows you the voltage of +3.3V/+5V/+12V.
SHUTDOWN TEMPERATURE:
This item allows you to set the CPU shutdown Temperature. This function is only
effective under Window 98 ACPI mode.
5-11-2-8. Frequency/Voltage Control
Auto Detect DIMM/PCI Clk
Spread Spectrum
CPU Clock
Intel CPU Ratio
↑↓→←:Move Enter: Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5: Previous Values
AUTO DETECT DIMM/PCI CLK:
This item allows you to enable or disable auto detect DIMM/PCI Clock.
SPREAD SPECTRUM:
This item allows you to enable or disable the spread spectrum modulate.
CPU CLOCK RATIO:
This CPU clock ratio will be auto detected by system and can not be changed.
Phoenix – Award CMOS Setup Utility
Frequency/Voltage Control
F6:Fail-Safe Defaults
- 44 -
< Screen shows all default setting >
[Enabled]
Item Help
[Enabled]
Menu Level
100
Default
This item is for VIA
C3 CPU Ratio
adjustment.
F7:Optimized Defaults
„
