SmartLocker AX

4 Operation

5 Battery change

EN
31. Close the lid downwards.
29
32. Gently press the lid against the floor and unscrew
the lower screw counterclockwise (0.9 mm hex
wrench) until it is flush with the lid surface.
30
9 SmartLocker AX is completely assembled.
Present an ID medium to the SmartLocker AX.

SmartLocker AX signals reaction (see
9
[ 42] ).
}
9 SmartLocker AX reacts as configured.
ü SmartLocker's back accessible.
Slot screwdriver available.
ü
1. Put the slot screwdriver in the intended notch.
31
2. Turn the screwdriver as shown to lift the battery lid.
Push the lid to the case's edge.
32
33
3. Change the battery. (see
[ 43] ).
}
4. Hook in the lid's long flap first, then hook in the the
short flap.
34
4. Operation
Signalisation
Technical specifications
41 / 124
