3. Initial operation
Inner side of door up to dead-bolt
stop (A)
0.0 mm to 5.95 mm
6.05 mm to 7.25 mm
7.35 mm to 8.85 mm
8.95 mm to 10.45 mm
10.55 mm to 10.95 mm
11.05 mm to 12.25 mm
12.35 mm to 13.85 mm
13.95 mm to 15.45 mm
15.55 mm to 15.95 mm
16.05 mm to 17.25 mm
17.35 mm to 18.85 mm
18.95 mm to 20.45 mm
20.55 mm to 20.95 mm
21.05 mm to 22.25 mm
22.35 mm to 23.85 mm
36 / 124
1. Measure the distance between the inside of the
door and the dead-bolt stop (A), e.g. with the
depth rod of a caliper gauge.
2
2. Measure the thickness of the door/door panel (B).
3. Refer to the tables for the parts required from the
scope of delivery (adapter plates, dead-bolt fixture,
flange extensions and screw). Additional parts can
be ordered (see manual).
Adapter plate P
(LL.PLATE5)
None
None
None
None
5 mm
5 mm
5 mm
5 mm
2 × 5 mm
2 × 5 mm
2 × 5 mm
2 × 5 mm
3 × 5 mm
3 × 5 mm
3 × 5 mm
SmartLocker AX
Dead-bolt fix-
ture R
4 (5.9 mm)
3 (7.5 mm)
2 (9.1 mm)
1 (10.4 mm)
4 (5.9 mm)
3 (7.5 mm)
2 (9.1 mm)
1 (10.4 mm)
4 (5.9 mm)
3 (7.5 mm)
2 (9.1 mm)
1 (10.4 mm)
4 (5.9 mm)
3 (7.5 mm)
2 (9.1 mm)
