OSD Menu Adjust
_
1
SHARPNESS
Set the sharpness of the image. The Sharpness values can be increased or lowered according to
the AGC levels in the camera's view. If AUTO is selected, adjust the following values :
- LEVEL : Set the sharpness level. The higher the number, the sharper the image will appear.
- START AGC : Select the AGC value where the image's shart lines may start to appear smeared
in low light.
- END AGC : Select end AGC value for sharpness smearing in low light. Once the AGC values pass
the set END AGC, the image's sharp lines will no longer appear smeared if the environment
gets darker.
2
MONITOR
Adjust the camera's signal according to the monitor you are
using.
- LCD Mode : If using and LCD monitor, adjust the following settings:
1. GAMMA - Set the gamma level from 0.45~1.00 / USER
0.55 is default setting.
2. BLUE GAIN - Set the blue levels from 0~100.
3. RED GAIN - Set the red levels from 0~100.
- CRT ode : If using an CRT monitor, adjust the following settings :
1. BLUE GAIN - Set the blue levels from 0~100.
2. RED GAIN - Set the red levels from 0~100.
3
LSC (Lens Side Compansation)
The LSC function improves the brightness around the lens.
4
VIDEO OUT
If you need to change the camera's video output, select from NTSC or PAL.
Reboot the camera after making any changes to the video signal settings.
LCD
GAMMA 0.55
BLUE GAIN ----64
RED GAIN ----64
RETURN RET
CRT
BLUE GAIN ----64
RED GAIN ----64
RETURN RET
