OSD Menu Lens
_
1
MANUAL
Manual mode supports the fixed board lens or the manual iris lens.
2
P-IRIS
If the camera includes a P-Iris lens, you can select this option to adjust the lens and iris settings.
If P-Iris is selected, adjust the following :
MODE : Select from AUTO or MANUAL. If AUTO is selected, the camera's iris and lens will be adjusted
automatically.
LIMIT : If MANUAL is selected, the camera's iris can be adjusted manually using the LIMIT value.
MAIN MENU
LENS P-IRIS
EXPOSURE
BACKLIGHT OFF
WHITE BAL ATW
DAY&NIGHT AUTO
NR
SPECIAL
ADJUST
EXIT SAVE&END
3
DC
DC lens mode allows you to setup the camera for indoor or outdoor modes.
If DC is selected adjust the following options :
MODE : Select from INDOOR or OUTDOOR.
IRIS SPEED : Set the reaction speed of the camera's Lens iris.
If OUTDOOR mode is selected, you can adjust the minimum and maximum shutter speed. By default,
the MIN SHU is set to 1/30. The MAX SHU can be adjusted as needed. The lower the number, the darker
the image will appear in bright areas.
MAIN MENU
LENS DC
EXPOSURE
BACKLIGHT OFF
WHITE BAL ATW
DAY&NIGHT AUTO
NR
SPECIAL
ADJUST
EXIT SAVE&END
P-IRIS MODE
MODE AUTO
LIMIT ---
RETURN RET
DC LENS MODE
MODE INDOOR
IRIS SPEED ---8
RETURN RET
OUTDOOR MODE
MIN SHU 1/30
MAX SHUT 1/60
RETURN RET
