OSD Menu Special (CONT.)
_
8
DEFECT (CONT.)
- BLACK DPC :
1. POS/SIZE : Set the size and position for the DPC Zone.
Use the joystick controller on the camera's board to adjust
the zone's position. Press the enter key and use the joystick
controller to adjust the zone's size.
2. START : Press START to begin the DPC test. The screen will
get bright and compensate for the black defect.
3. DPC VIEW : Show the Defect pixels whichhave been compensated.
4. LEVEL : Set the range of DPC application.
9
RS485
- CAM ID : Set the camera's ID from 0~255.
- ID DISPLAY : Select to show or hide the camera ID on the screen.
- BAUDRATE : Set the camera's baudrate.
Select from : 2400/4800/9600/19200/38400. Default is 9600.
BLACK DPC
POS/SIZE
START
DPC VIEW OFF
LEVEL ----100
RETURN RET
RS485
CAM ID ----1
ID DISPLAY OFF
BAUDRATE 9600
RETURN RET
