OSD Menu White Balance
_
1
ATW
Auto Tracking White Balance Control mode compensates for
color temperature changes between 2400K° and 11000K°.
2
PUSH
Push fixes the white balace based on the current lighting auto-
matically. To use this function, press the ENTER key for five sec.
3
MANUAL
Control the white balance manually by changing RED and BLUE.
RED : Adjusts the low color temperature in the image between
0~100. The default value is 44.
BLUE : Adjusts the low color temperature in the image between
0~100. The default value is 44.
4
AWB
Auto White Balance Control mode compensates for color temper-
ature changes lower than 2500K° and higher than 12000K°.
MAIN MENU
LENS MANUAL
EXPOSURE
BACKLIGHT OFF
WHITE BAL ATW
DAY&NIGHT AUTO
NR
SPECIAL
ADJUST
EXIT SAVE&END
MAIN MENU
LENS P-IRIS
EXPOSURE
BACKLIGHT OFF
WHITE BAL MANUAL
DAY&NIGHT AUTO
NR
SPECIAL
ADJUST
EXIT SAVE&END
MANUAL WB
BLUE ----42
RED ----40
RETURN RET
