Installation-
Using Mount Bolt & Nut
1
Detach the camera's cover dome from the
camera's module by unscrewing the three cover
dome screws.
2
Using the camera or mounting template, mark
and drill the necessary holes in the wall or ceiling.
3
Secure the two long mounting screws to the
camera's base.
4
Pull wires through and make connections.
5
Mount the camera to the mounting surface
using the 2 mounting nuts.
6
Secure the camera's cover dome onto the
camera base to complete the installation.
Template Sheet
