INSTALLATION

CONNECTIONS

CONNECTING THE TELEPHONE LINE CORD

Plug one end of the telephone line cord into the jack on the machine marked
"LINE." Plug the other side into a standard (RJ11C) single-line telephone
wall jack. Be sure not to plug this telephone line cord into the "TEL" jack.
The "TEL" jack is used to attach an extension telephone or answering
machine to the machine. (See "CONNECTING OTHER DEVICES" (p.12))
If your area experiences a high incidence of lightning or power
Note
surges, we recommend that you install surge protectors for the
power and telephone lines. Surge protectors can be purchased
from your retailer or at most telephone specialty stores.
ABOUT THE OPERATION MANUALS
The operation manuals for the machine are as follows:
Operation Manual (for facsimile) (this manual)
This manual explains the procedures for using the machine as a fax machine.
This manual only explains the fax functions of the machine. For general information on using the machine, including
safety information, installation, paper loading, removal of paper misfeeds, and peripheral equipment, see the
operation manual for the machine.
Operation Manual (for general information)
Explains the machine and how to use it as a copier. Also explains how to install the software that allows the machine
to be used as a printer and scanner for your computer.
The following information is contained in the operation manual for the machine :
OPERATION MANUAL contents
CAUTIONS
PART NAMES
CHECKING PACKED COMPONENTS AND
ACCESSORIES
PREPARING THE MACHINE FOR INSTALLATION
INSTALLING THE TD CARTRIDGE
POWER ON AND OFF
LOADING THE PAPER TRAY
BYPASS FEED (including special paper)
Online Manual (on the CD-ROM)
This manual explains the procedures for using the machine as a printer and a scanner.
Page OPERATION MANUAL contents
3 CHANGING A TRAY'S PAPER SIZE
SETTING
9
MISFEED REMOVAL
12
TD CARTRIDGE REPLACEMENT
13 DRUM CARTRIDGE REPLACEMENT
14 CHECKING THE TOTAL COUNT AND
DRUM CARTRIDGE LIFE
16
CLEANING THE MACHINE
19
ABOUT SUPPLIES AND OPTIONS
21
